Monochrome Passive LCD Displays

Various display pattern:  customized icon, segment, character, graphic


Multiple display mode:  options include LCD technology of TN, HTN, VA, STN, FSTN, DFSTN, and mode of transflective, transmissive or reflective


Easy customization:  easy to make a tooling to design your unique display and upgrade your product appearance


Wide-temperature Performance:  supports ultra wide-temperature application and can meet extremely operating temperature range up to -40~90°C


Green and energy-saving: the operating current is just at uA. Battery power or solar power is enough for its low power consumption


Stable longevity guarantee:  the long-term stable supply is guaranteed


Ø  COG(Chip-on-Glass) is the dominant display structure. Its main parts includes LCD, (COG)IC,FPC and backlight, with the feature of simple structure, thin-thickness and effective-cost.



Product List

Part No.ResolutionModule Outline(mm)V.A Size(mm)Dot Size(mm)Driver ICLCD TypeFile
FG-64640164*6415.5*21.0*1.312*120.155*0.155ST7567AFSTNdownload
FG-12832014128*3262.2*32.2*4.556.8*18.80.38*0.38ST7665RFSTNdownload
FG-1283203128*3258.0*28.0*2.855.0*19.00.38*0.48ST7567GDFSTNdownload
FG-12832025128*3258.0*25.5*4.753.0*15.50.37*0.36ST7565RFSTNdownload
FG-12864136128*6450.2*39.2*4.5044.00*29.000.29*0.29ST7567FSTNdownload
FG-12864016128*6443.10*27.46*1.739.5*20.240.28*0.28ST7567AFSTNdownload
FG-12864138128*6447.00*35.00*3.343.1*26.70.30*0.365ST7567FSTNdownload
FG-12864017128*6436.00*32.50*4.330.70*23.000.205*0.308UC1701XFSTNdownload
FG-12864D128*64100.50*25.00*5.090.00*16.50.675*0.223ST7567FSTNdownload
FG-12864018128*6450.20*39.2*2.1044.0*29.00.29*0.36ST7567FSTNdownload
FG-12864084128*6476.00*45.00*5.247.33*30.000.34*0.35ST7567STN Y/Gdownload
FG-12864077128*6483.5*44.0*6.073.0*39.00.48*0.48ST7567FSTNdownload
FG-12864059128*6458.9*40.5*5.353.6*28.60.35*0.36ST7567FSTNdownload
FG-12864066128*6435.0*31.4*2.730.7*23.00.205*0.308ST7567A FSTNdownload
FG-12864103128*6453.1*40.0*5.046.5*29.50.3108*0.3816ST7567FSTNdownload
FG-1284805128*6444.50*25.0*4.042.50*17.30.28*0.28ST7567A FSTNdownload
FG-12864053128*6471.3*48.2*4.8565.5*38.00.45*0.49ST7567FSTNdownload
FG-12864076128*6426.7*19.26*1.722.34*11.610.154*0.154ST7567A STN BLUEdownload
FG-12864039128*6428.58*19.5*1.726.58*14.860.18*0.20ST7567A FSTNdownload
FG-12864081128*6456.4*33.0*2.853.4*25.00.33*0.32ST7567STN Y/Gdownload
FG-12864083128*6456.0*39.0*5.353*27.50.35*0.36ST7567DFSTNdownload
FG-12864087128*6470.5*44.35*64.5*32.290.46*0.46ST7567A FSTNdownload
FG-12864012128*6440.025.9*1.7537.0*19.00.24*0.24ST7567DFSTNdownload
FG-12864088128*6428.5*20.0*1.826.5*14.00.16*0.17ST7567STN BLUEdownload
FG-12864085128*6456.6*38.6*2.853.6*28.60.35*0.36ST7567STN BLUEdownload
FG-12864093128*6453.0*40.0*5.046.5*29.50.3055*0.3755ST7567STN Y/Gdownload
FG-12864078128*6471.2*48.2*5.066.0*37.650.45*0.49ST7565RSTN BLUE
download
FG12864018128*6450.2*39.2*4.4544.0*29.00.29*0.36ST7567FSTNdownload
FG-12864096128*6459.3*36.7*4.855.0*27.40.355*0.34ST7567DFSTNdownload
FG-12864098128*6435.0*31.5*2.930.7*23.00.195*0.298UC1701XFSTNdownload
FG-12864049128*6457.0*40.0*2.854.0*32.60.3514*0.410ST7567FSTNdownload
FG-12864019128*6447.0*37.6*2.943.4*28.00.315*0.385ST7567FSTNdownload
FG-12864139128*6477.9*49.4*5.173.0*39.00.48*0.48ST7567GFSTNdownload
FG-12864156128*6451.7*36.2*4.047.1*26.50.33*0.33ST7565RFSTNdownload
FG-12864058128*6433.5*31.0*1.730.0*22.00.20*0.28ST7565RFSTNdownload
FG-12864071128*6466.5*43.8*2.063.9*36.50.41*0.41ST7567STN Graydownload
FG-12812806128*6452.78*59.18*2.048.78*48.780.322*0.322ST7571STN Y/Gdownload
FG-1286408128*6468.8*50*2.865.8*390.45*0.49ST7565RSTN Y/Gdownload
FG-12864036128*6428.58*19.5*1.726.58*14.840.18*0.1988ST7567AFSTNdownload
FG-12864031128*6442.3*33*2.839.8*25.50.26*0.33ST7567DFSTNdownload
FG-1286407128*6448*32/37*2.0544*290.29*0.36ST7565RFSTNdownload
FG-1326406132*6447.0*37.6*2.6544.0*28.00.285*0.35AIP31567STN Y/Gdownload
FG-961280296*12842.72*60.26*2.736.88*49.060.337*0.341ST7571FSTNdownload
FG-961280596*12836.00*51.85*2.031.2*40.30.252*0.252ST7571FSTNdownload
FG-12812802128*12867.00*44.5*4.364.0*36.00.45*0.23ST7571FSTNdownload
FG-12812807128*12843.5*42.0*1.740.5*33.50.255*0.21ST7571FSTNdownload
FG-12812803128*12849*55*2.845.4*43.90.28*0.30UC1617SFSTNdownload
FG-1606402160*6451.5*29.9*4.046.5*20.50.25*0.25IST3020FSTNdownload
FG-12864F160*6432.25*24*2.929*16.350.18*0.20UC1701CFSTNdownload
FG-16096A160*9663.98*45.66*3.559.58**35.760.31*0.31ST75256FSTNdownload
FG-1926407192*6485.3*42.5*4.078.6*29.80.386*0.426UC1609cGAADFSTNdownload
FG-19216001192*16071.3*69.3*7.566.0*56.00.30*0.30UC1698UFSTNdownload
FG-24016005240*16084.55*61.2*4.878.35*48.00.255*0.27ST75256FSTNdownload
FG-24016003240*16055.0*48.0*4.851.4*38.00.18*0.202ST75256FSTNdownload
FG-240160A240*16060.0*52.0*5.856.0*38.70.1965*0.1965UC1698UFSTNdownload
FG-24016001240*16076.9*63.9*3.571.9*51.40.250*0.265ST75256FSTNdownload
FG-24016004
240*16073.1*58.1*3.568.9*48.50.250*0.265ST75256FSTNdownload
FG-24016008240*16076.9*63.9*3.571.9*51.40.250*0.265ST75256FSTNdownload
FG-13516001
135*160
40.32*56.26*2.95
36.88*47.16
0.250*0.261
ST75256
FSTNdownload
FG-16016004160*16076.9*63.9*3.560.0*60.00.420*0.320UC1628FSTNdownload
FG-12864108128*6437.75*25.60*2.5535.55*18.700.252*0.252
ST7567A
FSTNdownload
